ESDA7P60-1U1M دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
ESDA7P60-1U1M
|
|
حجم فایل
|
49.916
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
10
|
مشخصات فنی
-
RoHS:
true
-
Category:
TVS/Fuse/Board Level Protection/ESD Protection Devices
-
Datasheet:
STMicroelectronics ESDA7P60-1U1M
-
Number of Lines:
1
-
Clamping Voltage@Ipp:
11.6V
-
Operating Temperature:
-55°C~+150°C@(Tj)
-
Breakdown Voltage (VBR):
6.4V
-
Peak Pulse Power(Ppp)@8/20us:
700W
-
Junction Capacitance(Cj)@1MHz:
-
-
Peak Pulse Current(Ipp)@8/20us:
60A@(8/20us)
-
Reverse Stand-Off Voltage (Vrwm):
5V
-
Package:
1610
-
Manufacturer:
STMicroelectronics
-
Series:
ESDA
-
Packaging:
Cut Tape (CT)
-
Part Status:
Active
-
Type:
Zener
-
Unidirectional Channels:
1
-
Voltage - Reverse Standoff (Typ):
5V
-
Voltage - Breakdown (Min):
6.4V
-
Voltage - Clamping (Max) @ Ipp:
11.6V
-
Current - Peak Pulse (10/1000µs):
60A (8/20µs)
-
Power - Peak Pulse:
700W
-
Power Line Protection:
No
-
Applications:
General Purpose
-
Capacitance @ Frequency:
-
-
Mounting Type:
Surface Mount
-
Package / Case:
0603 (1610 Metric)
-
Supplier Device Package:
1610
-
Base Part Number:
ESDA7
-
detail:
11.6V Clamp 60A (8/20µs) Ipp Tvs Diode Surface Mount 1610
