HSP051-4N10 دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
HSP051-4N10
|
|
حجم فایل
|
71.497
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
12
|
مشخصات فنی
-
RoHS:
true
-
Category:
TVS/Fuse/Board Level Protection/ESD Protection Devices
-
Datasheet:
STMicroelectronics HSP051-4N10
-
Number of Lines:
4
-
Clamping Voltage@Ipp:
10V
-
Breakdown Voltage (VBR):
4.5V
-
Package:
UQFN-10L
-
Manufacturer:
STMicroelectronics
-
Series:
HSP
-
Packaging:
Cut Tape (CT)
-
Part Status:
Active
-
Type:
Steering (Rail to Rail)
-
Unidirectional Channels:
4
-
Voltage - Reverse Standoff (Typ):
3.6V
-
Voltage - Breakdown (Min):
4.5V
-
Voltage - Clamping (Max) @ Ipp:
10V
-
Current - Peak Pulse (10/1000µs):
1A (8/20µs)
-
Power - Peak Pulse:
-
-
Power Line Protection:
Yes
-
Applications:
HDMI
-
Capacitance @ Frequency:
0.4pF @ 200MHz ~ 2.5GHz
-
Operating Temperature:
-40°C ~ 150°C (TJ)
-
Mounting Type:
Surface Mount
-
Package / Case:
10-XFDFN
-
Supplier Device Package:
10-uQFN (1.9x1)
-
Base Part Number:
HSP051
-
detail:
10V Clamp 1A (8/20µs) Ipp Tvs Diode Surface Mount 10-uQFN (1.9x1)
