STR1P2UH7 دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
STR1P2UH7
|
|
حجم فایل
|
507.937
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
12
|
مشخصات فنی
-
Manufacturer:
STMicroelectronics
-
Series:
STripFET™ H7
-
Packaging:
Cut Tape (CT)
-
Part Status:
Obsolete
-
FET Type:
P-Channel
-
Technology:
MOSFET (Metal Oxide)
-
Drain to Source Voltage (Vdss):
20V
-
Current - Continuous Drain (Id) @ 25°C:
1.4A (Ta)
-
Drive Voltage (Max Rds On, Min Rds On):
1.8V, 4.5V
-
Rds On (Max) @ Id, Vgs:
100mOhm @ 700mA, 4.5V
-
Vgs(th) (Max) @ Id:
1V @ 250µA
-
Gate Charge (Qg) (Max) @ Vgs:
4.8nC @ 4.5V
-
Vgs (Max):
±8V
-
Input Capacitance (Ciss) (Max) @ Vds:
510pF @ 10V
-
FET Feature:
-
-
Power Dissipation (Max):
350mW (Tc)
-
Operating Temperature:
150°C (TJ)
-
Mounting Type:
Surface Mount
-
Supplier Device Package:
SOT-23
-
Package / Case:
TO-236-3, SC-59, SOT-23-3
-
Base Part Number:
STR1
-
detail:
P-Channel 20V 1.4A (Ta) 350mW (Tc) Surface Mount SOT-23
