ESDA25P35-1U1M دیتاشیت

ESDA25P35-1U1M

مشخصات دیتاشیت

نام دیتاشیت ESDA25P35-1U1M
حجم فایل 52.563 کیلوبایت
نوع فایل pdf
تعداد صفحات 9

دانلود دیتاشیت ESDA25P35-1U1M

دانلود دیتاشیت

سایر مستندات

Power over Ethernet Proctection Flyer 2 pages

ESDA25P35-1U1M Datasheet 9 pages

مشخصات فنی

  • RoHS: true
  • Category: TVS/Fuse/Board Level Protection/ESD Protection Devices
  • Datasheet: STMicroelectronics ESDA25P35-1U1M
  • Number of Lines: 1
  • Clamping Voltage@Ipp: 41V
  • Operating Temperature: -55°C~+150°C@(Tj)
  • Breakdown Voltage (VBR): 23.3V
  • Peak Pulse Power(Ppp)@8/20us: 1.4kW
  • Junction Capacitance(Cj)@1MHz: -
  • Peak Pulse Current(Ipp)@8/20us: 35A@(8/20us)
  • Reverse Stand-Off Voltage (Vrwm): 22V
  • Package: DFN1610-2
  • Manufacturer: STMicroelectronics
  • Series: ESDA
  • Packaging: Cut Tape (CT)
  • Part Status: Active
  • Type: Zener
  • Unidirectional Channels: 1
  • Voltage - Reverse Standoff (Typ): 22V
  • Voltage - Breakdown (Min): 23.3V
  • Voltage - Clamping (Max) @ Ipp: 41V
  • Current - Peak Pulse (10/1000µs): 35A (8/20µs)
  • Power - Peak Pulse: 1400W (1.4kW)
  • Power Line Protection: No
  • Applications: General Purpose
  • Capacitance @ Frequency: -
  • Mounting Type: Surface Mount
  • Package / Case: 2-UDFN
  • Supplier Device Package: 1610
  • Base Part Number: ESDA25
  • detail: 41V Clamp 35A (8/20µs) Ipp Tvs Diode Surface Mount 1610
