TPD4E101DPWR دیتاشیت

TPD4E101DPWR

مشخصات دیتاشیت

نام دیتاشیت TPD4E101DPWR
حجم فایل 64.505 کیلوبایت
نوع فایل pdf
تعداد صفحات 8

مشاهده دیتاشیت TPD4E101DPWR

دانلود دیتاشیت

سایر مستندات

TPD4E101 20 pages

مشخصات فنی

  • RoHS: true
  • Category: TVS/Fuse/Board Level Protection/ESD Protection Devices
  • Datasheet: Texas Instruments TPD4E101DPWR
  • Clamping Voltage@Ipp: 13V
  • Operating Temperature: -40°C~+125°C@(Ta)
  • Breakdown Voltage (VBR): 6V
  • Peak Pulse Power(Ppp)@8/20us: 40W
  • Junction Capacitance(Cj)@1MHz: -
  • Peak Pulse Current(Ipp)@8/20us: 3A@(8/20us)
  • Reverse Stand-Off Voltage (Vrwm): 5.5V
  • Package: X2-SON-4-EP(0.8x0.8)
  • Manufacturer: Texas Instruments
  • Voltage - Reverse Standoff (Typ): 5.5V (Max)
  • Power - Peak Pulse: 40W
  • Applications: General Purpose
  • Package / Case: 4-XFDFN Exposed Pad
  • Bidirectional Channels: 4
  • Current - Peak Pulse (10/1000µs): 3A (8/20µs)
  • Voltage - Breakdown (Min): 6V
  • Mounting Type: Surface Mount
  • Packaging: Cut Tape (CT)
  • Type: Zener
  • Power Line Protection: No
  • Capacitance @ Frequency: -
  • Part Status: Active
  • Series: -
  • Supplier Device Package: 4-X2SON (0.8x0.8)
  • Base Part Number: TPD4E
  • Voltage - Clamping (Max) @ Ipp: 13V (Typ)
  • detail: 13V (Typ) Clamp 3A (8/20µs) Ipp Tvs Diode Surface Mount 4-X2SON (0.8x0.8)
