دیتاشیت EMIF02-SPK02F2
مشخصات دیتاشیت
| نام دیتاشیت |
EMIF02-SPK02F2
|
| حجم فایل |
226.803
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
12
|
مشخصات
-
Manufacturer:
STMicroelectronics
-
Series:
EMIF
-
Packaging:
Tape & Reel (TR)
-
Part Status:
Active
-
Type:
Low Pass
-
Filter Order:
3rd
-
Technology:
RC (Pi)
-
Number of Channels:
2
-
Center / Cutoff Frequency:
20MHz (Cutoff)
-
Attenuation Value:
45dB @ 900MHz
-
Resistance - Channel (Ohms):
0.35
-
Values:
R = 800mOhms, C = 315pF
-
ESD Protection:
Yes
-
Operating Temperature:
-
-
Applications:
Data Lines for Mobile Devices
-
Voltage - Rated:
-
-
Mounting Type:
Surface Mount
-
Package / Case:
5-WFBGA, FCBGA
-
Size / Dimension:
0.050" L x 0.035" W (1.26mm x 0.89mm)
-
Height:
0.028" (0.72mm)
-
Base Part Number:
EMIF02
-
detail:
RC (Pi) EMI Filter 3rd Order Low Pass 2 Channel R = 800mOhms, C = 315pF 5-WFBGA, FCBGA
