TL971, TL972, TL974 دیتاشیت

TL971, TL972, TL974

مشخصات دیتاشیت

نام دیتاشیت TL971, TL972, TL974
حجم فایل 1776.237 کیلوبایت
نوع فایل pdf
تعداد صفحات 34

دانلود دیتاشیت TL971, TL972, TL974

دانلود دیتاشیت

سایر مستندات

TI TL972IDGKR 35 pages

مشخصات فنی

  • RoHS: true
  • Category: Operational Amplifier/Comparator/Operational Amplifier
  • Datasheet: Texas Instruments TL974IDR
  • Rail to Rail: 轨到轨
  • -3db Bandwidth: -
  • Output Current: 80mA
  • Number of Circuits: 4
  • Operating Temperature: -40°C~+125°C
  • Current - Input Bias(Ib): 200nA
  • Gain Bandwidth Product(GBP): 12MHz
  • Package: SOP-14
  • Manufacturer: Texas Instruments
  • Current - Output / Channel: 80mA
  • Slew Rate: 5V/µs
  • Voltage - Input Offset: 1mV
  • Part Status: Active
  • Packaging: Cut Tape (CT)
  • Supplier Device Package: 14-SOIC
  • Package / Case: 14-SOIC (0.154", 3.90mm Width)
  • Voltage - Supply, Single/Dual (±): 2.7V ~ 12V, ±1.35V ~ 6V
  • Series: -
  • Output Type: Rail-to-Rail
  • Base Part Number: TL974
  • Current - Supply: 2mA
  • Mounting Type: Surface Mount
  • Amplifier Type: General Purpose
  • Current - Input Bias: 200nA
  • Gain Bandwidth Product: 12MHz
  • detail: General Purpose Amplifier 4 Circuit Rail-to-Rail 14-SOIC
