STG3157CTR دیتاشیت

مشخصات دیتاشیت

مشاهده دیتاشیت STG3157CTR	دانلود دیتاشیت

STG3157 20 pages

RoHS: true
Category: Communication Interface Chip/UART/485/232/Analog Switches / Multiplexers
Datasheet: STMicroelectronics STG3157CTR
Turn-on time: 15ns
Turn-off time: 10ns
Supply Voltage: 1.65V~4.3V
Switch Circuit: SPDT(SPDT)
Number of Channels: 1
On-State Resistance (Max): 15Ω
Package: SOT-323-6
Manufacturer: STMicroelectronics
Series: -
Packaging: Cut Tape (CT)
Part Status: Active
Multiplexer/Demultiplexer Circuit: 2:1
Number of Circuits: 1
Channel-to-Channel Matching (ΔRon): 100mOhm
Voltage - Supply, Single (V+): 1.65V ~ 4.3V
Voltage - Supply, Dual (V±): -
Switch Time (Ton, Toff) (Max): 15ns, 10ns
-3db Bandwidth: 250MHz
Charge Injection: 23pC
Channel Capacitance (CS(off), CD(off)): 5pF
Current - Leakage (IS(off)) (Max): 100nA
Crosstalk: -55dB @ 10MHz
Operating Temperature: -55°C ~ 125°C (TA)
Mounting Type: Surface Mount
Package / Case: 6-TSSOP, SC-88, SOT-363
Supplier Device Package: SOT-323-6L
Base Part Number: STG3157
detail: 1 Circuit IC Switch 2:1 15Ohm SOT-323-6L
