دیتاشیت Z0109MA 1AA2

Z0109MA 1AA2

مشخصات دیتاشیت

نام دیتاشیت Z0109MA 1AA2
حجم فایل 41.708 کیلوبایت
نوع فایل pdf
تعداد صفحات 12

Z0109MA 1AA2

دانلود دیتاشیت

سایر مستندات

Z01 Series 16 pages

مشخصات فنی

  • RoHS: true
  • Category: Triode/MOS Tube/Transistor/TRIACs
  • SCR Type: 门极灵敏型-High Speed
  • Datasheet: STMicroelectronics Z0109MA 1AA2
  • Holding Current (Ih): 10mA
  • Operating Temperature: -40°C~+125°C@(Tj)
  • Gate Trigger Current(Igt): 10mA
  • Gate Trigger Voltage (Vgt): 1.3V
  • RMS On-State Current(It (rms)): 1A
  • Peak Repetitive Off?State Voltage (Vdrm): 600V
  • Package: TO-92
  • Manufacturer: STMicroelectronics
  • Series: -
  • Packaging: Bulk
  • Part Status: Active
  • Triac Type: Logic - Sensitive Gate
  • Voltage - Off State: 600V
  • Current - On State (It (RMS)) (Max): 1A
  • Voltage - Gate Trigger (Vgt) (Max): 1.3V
  • Current - Non Rep. Surge 50, 60Hz (Itsm): 8A, 8.5A
  • Current - Gate Trigger (Igt) (Max): 10mA
  • Current - Hold (Ih) (Max): 10mA
  • Configuration: Single
  • Mounting Type: Through Hole
  • Package / Case: TO-226-3, TO-92-3 (TO-226AA)
  • Supplier Device Package: TO-92-3
  • Base Part Number: Z0109
  • detail: TRIAC Logic - Sensitive Gate 600V 1A Through Hole TO-92-3
