دیتاشیت SN74HC10N

SN54HC10, SN74HC10

مشخصات دیتاشیت

نام دیتاشیت SN54HC10, SN74HC10
حجم فایل 1261.042 کیلوبایت
نوع فایل pdf
تعداد صفحات 21

دانلود دیتاشیت SN54HC10, SN74HC10

SN54HC10, SN74HC10 Datasheet

مشخصات

  • Mounting Type: Through Hole
  • Logic Level - Low: 0.5V ~ 1.8V
  • Manufacturer: Texas Instruments
  • Current - Quiescent (Max): 2µA
  • Voltage - Supply: 2V ~ 6V
  • Series: 74HC
  • Number of Circuits: 3
  • Operating Temperature: -40°C ~ 85°C
  • Packaging: Tube
  • Package / Case: 14-DIP (0.300", 7.62mm)
  • Logic Level - High: 1.5V ~ 4.2V
  • Part Status: Active
  • Current - Output High, Low: 5.2mA, 5.2mA
  • Features: -
  • Base Part Number: SN74HC1
  • Supplier Device Package: 14-PDIP
  • Number of Inputs: 3
  • Logic Type: NAND Gate
  • Max Propagation Delay @ V, Max CL: 16ns @ 6V, 50pF
  • detail: NAND Gate IC 3 Channel 14-PDIP
