TPD2E2U06QDCKRQ1 دیتاشیت

TPD2E2U06QDCKRQ1

مشخصات دیتاشیت

نام دیتاشیت TPD2E2U06QDCKRQ1
حجم فایل 66.198 کیلوبایت
نوع فایل pdf
تعداد صفحات 25

مشاهده دیتاشیت TPD2E2U06QDCKRQ1

دانلود دیتاشیت

سایر مستندات

TPD2E2U06-Q1 Datasheet 25 pages

مشخصات فنی

  • RoHS: true
  • Category: TVS/Fuse/Board Level Protection/ESD Protection Devices
  • Datasheet: Texas Instruments TPD2E2U06QDCKRQ1
  • Number of Lines: 2
  • Clamping Voltage@Ipp: 12.4V
  • Operating Temperature: -40°C~+125°C@(Tj)
  • Breakdown Voltage (VBR): 6.5V
  • Peak Pulse Power(Ppp)@8/20us: 75W
  • Junction Capacitance(Cj)@1MHz: -
  • Reverse Stand-Off Voltage (Vrwm): 5.5V
  • Package: SC-70-3
  • Manufacturer: Texas Instruments
  • Voltage - Reverse Standoff (Typ): 5.5V (Max)
  • Power - Peak Pulse: 75W
  • Applications: Automotive, Ethernet
  • Package / Case: SC-70, SOT-323
  • Part Status: Active
  • Current - Peak Pulse (10/1000µs): 5.5A (8/20µs)
  • Voltage - Breakdown (Min): 6.5V
  • Mounting Type: Surface Mount
  • Packaging: Digi-Reel®
  • Type: Steering (Rail to Rail)
  • Power Line Protection: Yes
  • Capacitance @ Frequency: -
  • Series: Automotive, AEC-Q101
  • Supplier Device Package: SC-70-3
  • Base Part Number: TPD2E
  • Voltage - Clamping (Max) @ Ipp: 12.4V (Typ)
  • Unidirectional Channels: 2
  • detail: 12.4V (Typ) Clamp 5.5A (8/20µs) Ipp Tvs Diode Surface Mount SC-70-3
