CSD17585F5T دیتاشیت

CSD17585F5T

مشخصات دیتاشیت

نام دیتاشیت CSD17585F5T
حجم فایل 75.164 کیلوبایت
نوع فایل pdf
تعداد صفحات 17

مشاهده دیتاشیت CSD17585F5T

دانلود دیتاشیت

سایر مستندات

FemtoFET Surface Mount Guide 11 pages

CSD17585F5 Datasheet 14 pages

مشخصات فنی

  • RoHS: true
  • Category: Triode/MOS Tube/Transistor/MOSFETs
  • Datasheet: Texas Instruments CSD17585F5T
  • Operating Temperature: -55°C~+150°C@(Tj)
  • Power Dissipation (Pd): 500mW
  • Total Gate Charge (Qg@Vgs): 5.1nC@10V
  • Drain Source Voltage (Vdss): 30V
  • Input Capacitance (Ciss@Vds): 380pF@15V
  • Continuous Drain Current (Id): 5.9A
  • Gate Threshold Voltage (Vgs(th)@Id): 1.7V@250uA
  • Drain Source On Resistance (RDS(on)@Vgs,Id): 27mΩ@900mA,10V
  • Package: PicoStar-3
  • Manufacturer: Texas Instruments
  • Power Dissipation (Max): 500mW (Ta)
  • Drain to Source Voltage (Vdss): 30V
  • Rds On (Max) @ Id, Vgs: 27mOhm @ 900mA, 10V
  • Vgs (Max): 20V
  • FET Type: N-Channel
  • Drive Voltage (Max Rds On, Min Rds On): 4.5V, 10V
  • Technology: MOSFET (Metal Oxide)
  • Current - Continuous Drain (Id) @ 25°C: 5.9A (Ta)
  • FET Feature: -
  • Input Capacitance (Ciss) (Max) @ Vds: 380pF @ 15V
  • Packaging: Cut Tape (CT)
  • Package / Case: 3-SMD, No Lead
  • Part Status: Active
  • Series: FemtoFET™
  • Vgs(th) (Max) @ Id: 1.7V @ 250µA
  • Gate Charge (Qg) (Max) @ Vgs: 5.1nC @ 10V
  • Supplier Device Package: 3-PICOSTAR
  • Mounting Type: Surface Mount
  • Base Part Number: CSD175
  • detail: N-Channel 30V 5.9A (Ta) 500mW (Ta) Surface Mount 3-PICOSTAR
