STL40DN3LLH5 دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
STL40DN3LLH5
|
|
حجم فایل
|
821.027
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
16
|
مشخصات فنی
-
Manufacturer:
STMicroelectronics
-
Series:
STripFET™ V
-
Packaging:
Cut Tape (CT)
-
Part Status:
Active
-
FET Type:
2 N-Channel (Dual)
-
FET Feature:
Standard
-
Drain to Source Voltage (Vdss):
30V
-
Current - Continuous Drain (Id) @ 25°C:
40A
-
Rds On (Max) @ Id, Vgs:
18mOhm @ 5.5A, 10V
-
Vgs(th) (Max) @ Id:
1.5V @ 250µA
-
Gate Charge (Qg) (Max) @ Vgs:
4.5nC @ 4.5V
-
Input Capacitance (Ciss) (Max) @ Vds:
475pF @ 25V
-
Power - Max:
60W
-
Operating Temperature:
-55°C ~ 175°C (TJ)
-
Mounting Type:
Surface Mount
-
Package / Case:
8-PowerVDFN
-
Supplier Device Package:
PowerFlat™ (5x6)
-
Base Part Number:
STL40
-
detail:
Mosfet Array 2 N-Channel (Dual) 30V 40A 60W Surface Mount PowerFlat™ (5x6)
