- دیتاشیت TPS71518DCKR
TPS71518DCKR دیتاشیت
مشخصات دیتاشیت
| نام دیتاشیت | TPS71518DCKR |
|---|---|
| حجم فایل | 97.532 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 20 |
دانلود دیتاشیت TPS71518DCKR |
دانلود دیتاشیت |
|---|
سایر مستندات
TPS715xx Datasheet 22 pages
مشخصات فنی
- RoHS: true
- Category: Power Supply Chip/Linear Voltage Regulators (LDO)
- Datasheet: Texas Instruments TPS71518DCKR
- Output Current: 50mA
- Output Voltage: 1.8V
- Dropout Voltage: 0.75V@(50mA)
- Output Polarity: positive
- Number of Outputs: 1
- Maximum Input Voltage: 24V
- Operating Temperature: -40°C~+125°C
- Quiescent Current (Ground Current): 4.2uA
- Power Supply Rejection Ratio (PSRR): 60dB@(100kHz)
- Package: SC-70-5
- Manufacturer: Texas Instruments
- Voltage - Input (Max): 24V
- Current - Quiescent (Iq): 4.2µA
- Output Configuration: Positive
- Base Part Number: TPS715
- Voltage - Output (Min/Fixed): 1.8V
- Protection Features: Over Current
- Series: -
- Packaging: Cut Tape (CT)
- PSRR: 60dB (100kHz)
- Supplier Device Package: SC-70-5
- Package / Case: 5-TSSOP, SC-70-5, SOT-353
- Number of Regulators: 1
- Part Status: Active
- Output Type: Fixed
- Control Features: -
- Voltage - Output (Max): -
- Mounting Type: Surface Mount
- Voltage Dropout (Max): 0.75V @ 50mA
- Current - Output: 50mA
- detail: Linear Voltage Regulator IC 1 Output 50mA SC-70-5
