TS12A4516DBVR دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
TS12A4516DBVR
|
|
حجم فایل
|
62.157
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
20
|
مشخصات فنی
-
RoHS:
true
-
Category:
Communication Interface Chip/UART/485/232/Analog Switches / Multiplexers
-
Datasheet:
Texas Instruments TS12A4516DBVR
-
Turn-on time:
75ns
-
Turn-off time:
45ns
-
Switch Circuit:
SPST(SPST)-Normal Open
-
Number of Channels:
1
-
On-State Resistance (Max):
20Ω
-
Package:
SOT-23-5
-
Manufacturer:
Texas Instruments
-
Current - Leakage (IS(off)) (Max):
5nA
-
Voltage - Supply, Single (V+):
-
-
Voltage - Supply, Dual (V±):
±1V ~ 6V
-
Number of Circuits:
1
-
Channel-to-Channel Matching (ΔRon):
-
-
Package / Case:
SC-74A, SOT-753
-
Part Status:
Active
-
Supplier Device Package:
SOT-23-5
-
Switch Time (Ton, Toff) (Max):
75ns, 45ns
-
Packaging:
Cut Tape (CT)
-
-3db Bandwidth:
464MHz
-
Operating Temperature:
-40°C ~ 85°C (TA)
-
Mounting Type:
Surface Mount
-
Crosstalk:
-
-
Base Part Number:
TS12A
-
Series:
-
-
Channel Capacitance (CS(off), CD(off)):
5.5pF, 5.5pF
-
Multiplexer/Demultiplexer Circuit:
1:1
-
Charge Injection:
-13pC
-
detail:
1 Circuit IC Switch 1:1 20Ohm SOT-23-5
