دیتاشیت LM2931D-R

LM2931 Datasheet

مشخصات دیتاشیت

نام دیتاشیت LM2931 Datasheet
حجم فایل 1156.037 کیلوبایت
نوع فایل pdf
تعداد صفحات 26

دانلود دیتاشیت LM2931 Datasheet

LM2931 Datasheet Datasheet

مشخصات

  • Manufacturer: STMicroelectronics
  • Series: -
  • Packaging: Cut Tape (CT)
  • Part Status: Active
  • Output Configuration: Positive
  • Output Type: Adjustable
  • Number of Regulators: 1
  • Voltage - Input (Max): 26V
  • Voltage - Output (Min/Fixed): 2.5V
  • Voltage - Output (Max): 25.4V
  • Voltage Dropout (Max): 0.6V @ 100mA
  • Current - Output: 100mA
  • PSRR: 80dB (120Hz)
  • Control Features: -
  • Protection Features: Current Limit, Thermal Shutdown
  • Operating Temperature: -40°C ~ 125°C
  • Mounting Type: Surface Mount
  • Package / Case: 8-SOIC (0.154", 3.90mm Width)
  • Supplier Device Package: 8-SO
  • Base Part Number: LM2931
  • detail: Linear Voltage Regulator IC 1 Output 100mA 8-SO
