TLV702xx Datasheet دیتاشیت

مشخصات دیتاشیت

دانلود دیتاشیت TLV702xx Datasheet	دانلود دیتاشیت

RoHS: true
Category: Power Supply Chip/Linear Voltage Regulators (LDO)
Datasheet: Texas Instruments TLV70225DBVT
Output Current: 300mA
Output Voltage: 2.5V
Dropout Voltage: 0.38V@(300mA)
Output Polarity: positive
Number of Outputs: 1
Maximum Input Voltage: 5.5V
Operating Temperature: -40°C~+125°C@(Tj)
Quiescent Current (Ground Current): 55uA
Power Supply Rejection Ratio (PSRR): 68dB@(1kHz)
Package: SOT-23-5
Manufacturer: Texas Instruments
Current - Supply (Max): 370µA
Output Configuration: Positive
Package / Case: SC-74A, SOT-753
Packaging: Cut Tape (CT)
Protection Features: Over Current, Over Temperature, Reverse Polarity, Under Voltage Lockout (UVLO)
Number of Regulators: 1
Part Status: Active
Current - Quiescent (Iq): 55µA
Supplier Device Package: SOT-23-5
Voltage - Input (Max): 5.5V
Voltage - Output (Min/Fixed): 2.5V
Mounting Type: Surface Mount
PSRR: 68dB (1kHz)
Base Part Number: TLV702
Series: -
Output Type: Fixed
Control Features: Enable
Voltage - Output (Max): -
Voltage Dropout (Max): 0.38V @ 300mA
Current - Output: 300mA
detail: Linear Voltage Regulator IC 1 Output 300mA SOT-23-5
