TS12A4517DBVR دیتاشیت
مشخصات دیتاشیت
| نام دیتاشیت | TS12A4517DBVR |
|---|---|
| حجم فایل | 472.532 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 14 |
دانلود دیتاشیت TS12A4517DBVR |
دانلود دیتاشیت |
|---|
سایر مستندات
TS12A4516,17 19 pages
TS12A4516DBVR 20 pages
مشخصات فنی
- RoHS: true
- Category: Communication Interface Chip/UART/485/232/Analog Switches / Multiplexers
- Datasheet: Texas Instruments TS12A4517DBVR
- Turn-on time: 75ns
- Turn-off time: 45ns
- Switch Circuit: SPST(SPST)-Normally closed
- Number of Channels: 1
- On-State Resistance (Max): 20Ω
- Package: SOT-23-5
- Manufacturer: Texas Instruments
- Current - Leakage (IS(off)) (Max): 5nA
- Voltage - Supply, Single (V+): -
- Voltage - Supply, Dual (V±): ±1V ~ 6V
- Number of Circuits: 1
- Channel-to-Channel Matching (ΔRon): -
- Package / Case: SC-74A, SOT-753
- Part Status: Active
- Supplier Device Package: SOT-23-5
- Switch Time (Ton, Toff) (Max): 75ns, 45ns
- Packaging: Cut Tape (CT)
- -3db Bandwidth: 464MHz
- Operating Temperature: -40°C ~ 85°C (TA)
- Mounting Type: Surface Mount
- Crosstalk: -
- Base Part Number: TS12A
- Series: -
- Channel Capacitance (CS(off), CD(off)): 5.5pF, 5.5pF
- Multiplexer/Demultiplexer Circuit: 1:1
- Charge Injection: -13pC
- detail: 1 Circuit IC Switch 1:1 20Ohm SOT-23-5
