دیتاشیت TS3702IDT
مشخصات دیتاشیت
| نام دیتاشیت |
TS3702
|
| حجم فایل |
118.378
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
11
|
مشخصات
-
RoHS:
true
-
Category:
Operational Amplifier/Comparator/Comparators
-
Datasheet:
STMicroelectronics TS3702IDT
-
Output Type:
Push Pull
-
Supply Voltage:
2.7V~16V;1.35V~8V
-
Number of Elements:
-
-
Operating Temperature:
-40°C~+125°C
-
Input Bias Current (Ib):
1pA
-
Input Offset Voltage (Vos):
5mV
-
Input Hysteresis Voltage (Vhys):
-
-
Common Mode Rejection Ratio (CMRR):
85dB
-
Package:
SOP-8
-
Manufacturer:
STMicroelectronics
-
Series:
-
-
Packaging:
Cut Tape (CT)
-
Part Status:
Active
-
Type:
General Purpose
-
Voltage - Supply, Single/Dual (±):
2.7V ~ 16V, ±1.35V ~ 8V
-
Voltage - Input Offset (Max):
5mV @ 10V
-
Current - Input Bias (Max):
1pA @ 5V
-
Current - Output (Typ):
20mA
-
Current - Quiescent (Max):
25µA
-
CMRR, PSRR (Typ):
82dB CMRR
-
Propagation Delay (Max):
-
-
Hysteresis:
-
-
Package / Case:
8-SOIC (0.154", 3.90mm Width)
-
Mounting Type:
Surface Mount
-
Supplier Device Package:
8-SO
-
Base Part Number:
TS3702
-
detail:
Comparator General Purpose CMOS, Push-Pull 8-SO
