LD39015xx Datasheet

LD39015xx

Datasheet specifications

Datasheet's name LD39015xx
File size 271.993 KB
File type pdf
Number of pages 15

Download Datasheet LD39015xx

Download Datasheet

Other documentations

No other documentation was found!

Technical specifications

  • Manufacturer: STMicroelectronics
  • Series: -
  • Packaging: Cut Tape (CT)
  • Part Status: Active
  • Output Configuration: Positive
  • Output Type: Fixed
  • Number of Regulators: 1
  • Voltage - Input (Max): 5.5V
  • Voltage - Output (Min/Fixed): 2.5V
  • Voltage - Output (Max): -
  • Voltage Dropout (Max): 0.1V @ 100mA
  • Current - Output: 150mA
  • Current - Quiescent (Iq): 50µA
  • Current - Supply (Max): 70µA
  • PSRR: 65dB ~ 62dB (1kHz ~ 10kHz)
  • Control Features: Enable
  • Protection Features: Over Current, Over Temperature
  • Operating Temperature: -40°C ~ 125°C
  • Mounting Type: Surface Mount
  • Package / Case: SC-74A, SOT-753
  • Supplier Device Package: SOT-23-5
  • Base Part Number: LD39015
  • detail: Linear Voltage Regulator IC 1 Output 150mA SOT-23-5
