SMC30J20A دیتاشیت
مشخصات دیتاشیت
| نام دیتاشیت | SMC30J20A |
|---|---|
| حجم فایل | 136.054 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 10 |
دانلود دیتاشیت SMC30J20A |
دانلود دیتاشیت |
|---|
سایر مستندات
SMC30J 13 pages
SMC30J28CA 13 pages
مشخصات فنی
- RoHS: true
- Category: TVS/Fuse/Board Level Protection/TVS
- Datasheet: STMicroelectronics SMC30J20A
- Breakdown Voltage: 22.2V
- Unidirectional Channels: 1
- Maximum Clamping Voltage: 32.4V
- Reverse Leakage Current (Ir): 0.2uA
- Reverse Stand-Off Voltage (Vrwm): 20V
- Peak Pulse Current (Ipp)@10/1000us: 93A
- Peak Pulse Power Dissipation (Ppp)@10/1000us: 3kW
- Package: SMC(DO-214AB)
- Manufacturer: STMicroelectronics
- Series: SMC30J, TRANSIL™
- Packaging: Cut Tape (CT)
- Part Status: Active
- Type: Zener
- Voltage - Reverse Standoff (Typ): 20V
- Voltage - Breakdown (Min): 22.2V
- Voltage - Clamping (Max) @ Ipp: 32.4V
- Current - Peak Pulse (10/1000µs): 93A
- Power - Peak Pulse: 3000W (3kW)
- Power Line Protection: No
- Applications: General Purpose
- Capacitance @ Frequency: -
- Operating Temperature: -55°C ~ 175°C (TJ)
- Mounting Type: Surface Mount
- Package / Case: DO-214AB, SMC
- Supplier Device Package: SMC
- Base Part Number: SMC30J
- detail: 32.4V Clamp 93A Ipp Tvs Diode Surface Mount SMC
