دیتاشیت SMA6Txx(C)AY Datasheet

SMA6Txx(C)AY Datasheet

مشخصات دیتاشیت

نام دیتاشیت SMA6Txx(C)AY Datasheet
حجم فایل 635.483 کیلوبایت
نوع فایل pdf
تعداد صفحات 13

SMA6Txx(C)AY Datasheet

دانلود دیتاشیت

سایر مستندات

SMA6T82AY 13 pages

Protection Devices & Rectifiers Guide 16 pages

SMA6TY 13 pages

مشخصات فنی

  • RoHS: true
  • Category: TVS/Fuse/Board Level Protection/TVS
  • Datasheet: STMicroelectronics SMA6T39CAY
  • Breakdown Voltage: 37.1V
  • Bidirectional Channels: 1
  • Maximum Clamping Voltage: 69.7V
  • Reverse Leakage Current (Ir): 0.2uA
  • Reverse Stand-Off Voltage (Vrwm): 33.3V
  • Peak Pulse Current (Ipp)@10/1000us: 57A@8/20us
  • Peak Pulse Power Dissipation (Ppp)@10/1000us: 600W
  • Package: SMA(DO-214AC)
  • Manufacturer: STMicroelectronics
  • Series: Automotive, AEC-Q101, SMA6TY, TRANSIL™
  • Packaging: Cut Tape (CT)
  • Part Status: Active
  • Type: Zener
  • Voltage - Reverse Standoff (Typ): 33.3V
  • Voltage - Breakdown (Min): 37.1V
  • Voltage - Clamping (Max) @ Ipp: 69.7V
  • Current - Peak Pulse (10/1000µs): 57A (8/20µs)
  • Power - Peak Pulse: 600W
  • Power Line Protection: No
  • Applications: Automotive
  • Capacitance @ Frequency: -
  • Operating Temperature: -40°C ~ 150°C (TJ)
  • Mounting Type: Surface Mount
  • Package / Case: DO-214AC, SMA
  • Supplier Device Package: SMA (DO-214AC)
  • Base Part Number: SMA6T
  • detail: 69.7V Clamp 57A (8/20µs) Ipp Tvs Diode Surface Mount SMA (DO-214AC)
