دیتاشیت VIPER17LDTR

VIPER17 Datasheet

مشخصات دیتاشیت

نام دیتاشیت VIPER17 Datasheet
حجم فایل 2433.183 کیلوبایت
نوع فایل pdf
تعداد صفحات 31

دانلود دیتاشیت VIPER17 Datasheet

VIPER17 Datasheet Datasheet

مشخصات

  • RoHS: true
  • Category: Power Supply Chip/AC-DC Controllers & Regulators
  • Datasheet: STMicroelectronics VIPER17LDTR
  • Package: SOP-16
  • Manufacturer: STMicroelectronics
  • Series: VIPer™ plus
  • Packaging: Cut Tape (CT)
  • Part Status: Active
  • Output Isolation: Isolated
  • Internal Switch(s): Yes
  • Voltage - Breakdown: 800V
  • Topology: Flyback
  • Voltage - Start Up: 14V
  • Voltage - Supply (Vcc/Vdd): 8.5V ~ 23.5V
  • Duty Cycle: 70%
  • Frequency - Switching: 60kHz
  • Power (Watts): 10W
  • Fault Protection: Current Limiting, Over Temperature, Over Voltage
  • Control Features: -
  • Operating Temperature: -40°C ~ 150°C (TJ)
  • Package / Case: 16-SOIC (0.154", 3.90mm Width)
  • Supplier Device Package: 16-SO
  • Mounting Type: Surface Mount
  • Base Part Number: VIPER17
  • detail: Converter Offline Flyback Topology 60kHz 16-SO
