دیتاشیت UA7812CKTTR
مشخصات دیتاشیت
| نام دیتاشیت | UA7805,08,10,12,15,24 |
|---|---|
| حجم فایل | 1119.424 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 27 |
دانلود دیتاشیت UA7805,08,10,12,15,24 |
UA7805,08,10,12,15,24 Datasheet |
|---|
مشخصات
- Manufacturer: Texas Instruments
- Voltage - Input (Max): 30V
- Output Configuration: Positive
- Base Part Number: UA781
- Voltage - Output (Min/Fixed): 12V
- Protection Features: Over Current, Over Temperature, Reverse Polarity, Short Circuit
- Series: -
- Packaging: Cut Tape (CT)
- PSRR: 78dB (120Hz)
- Supplier Device Package: DDPAK/TO-263-3
- Package / Case: TO-263-4, D²Pak (3 Leads + Tab), TO-263AA
- Number of Regulators: 1
- Operating Temperature: 0°C ~ 125°C
- Part Status: Active
- Output Type: Fixed
- Control Features: -
- Voltage - Output (Max): -
- Mounting Type: Surface Mount
- Voltage Dropout (Max): 2V @ 1A
- Current - Output: 1.5A
- detail: Linear Voltage Regulator IC 1 Output 1.5A DDPAK/TO-263-3
