UCC28911DR دیتاشیت

UCC28911DR

مشخصات دیتاشیت

نام دیتاشیت UCC28911DR
حجم فایل 107.334 کیلوبایت
نوع فایل pdf
تعداد صفحات 56

مشاهده دیتاشیت UCC28911DR

دانلود دیتاشیت

سایر مستندات

UCC28910, UCC28911 Datasheet 55 pages

مشخصات فنی

  • RoHS: true
  • Category: Power Supply Chip/AC-DC Controllers & Regulators
  • Topology: Flyback
  • Datasheet: Texas Instruments UCC28911DR
  • Supply Voltage: 6.5V~30V
  • Output Isolation: Isolation
  • Breakdown Voltage: 700V
  • Switching Frequency: 420Hz~115kHz
  • Operating Temperature: -40°C~+125°C@(Tj)
  • Package: SOP-7
  • Manufacturer: Texas Instruments
  • Duty Cycle: -
  • Frequency - Switching: 420Hz ~ 115kHz
  • Part Status: Active
  • Power (Watts): 12W
  • Package / Case: 8-SOIC (0.154", 3.90mm Width), 7 Leads
  • Packaging: Cut Tape (CT)
  • Internal Switch(s): Yes
  • Fault Protection: Current Limiting, Over Temperature, Over Voltage
  • Voltage - Breakdown: 700V
  • Series: -
  • Control Features: -
  • Supplier Device Package: 7-SOIC
  • Mounting Type: Surface Mount
  • Base Part Number: UCC289
  • Voltage - Supply (Vcc/Vdd): 6.5V ~ 30V
  • Voltage - Start Up: 9.5V
  • detail: Converter Offline Flyback Topology 420Hz ~ 115kHz 7-SOIC
