T810-800B-TR دیتاشیت

T810-800B-TR

مشخصات دیتاشیت

نام دیتاشیت T810-800B-TR
حجم فایل 51.731 کیلوبایت
نوع فایل pdf
تعداد صفحات 21

دانلود دیتاشیت T810-800B-TR

دانلود دیتاشیت

سایر مستندات

BT(A,B)08, T8xx Datasheet 21 pages

مشخصات فنی

  • RoHS: true
  • Category: Triode/MOS Tube/Transistor/TRIACs
  • SCR Type: 门极灵敏型-High Speed
  • Datasheet: STMicroelectronics T810-800B-TR
  • Holding Current (Ih): 15mA
  • Operating Temperature: -40°C~+125°C@(Tj)
  • Gate Trigger Current(Igt): 10mA
  • Gate Trigger Voltage (Vgt): 1.3V
  • RMS On-State Current(It (rms)): 8A
  • Peak Repetitive Off?State Voltage (Vdrm): 800V
  • Package: TO-252
  • Manufacturer: STMicroelectronics
  • Series: -
  • Packaging: Cut Tape (CT)
  • Part Status: Active
  • Triac Type: Logic - Sensitive Gate
  • Voltage - Off State: 800V
  • Current - On State (It (RMS)) (Max): 8A
  • Voltage - Gate Trigger (Vgt) (Max): 1.3V
  • Current - Non Rep. Surge 50, 60Hz (Itsm): 80A, 84A
  • Current - Gate Trigger (Igt) (Max): 10mA
  • Current - Hold (Ih) (Max): 15mA
  • Configuration: Single
  • Mounting Type: Surface Mount
  • Package / Case: TO-252-3, DPak (2 Leads + Tab), SC-63
  • Supplier Device Package: DPAK
  • Base Part Number: T810
  • detail: TRIAC Logic - Sensitive Gate 800V 8A Surface Mount DPAK
