TPS79901QDRVRQ1 دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
TPS79901QDRVRQ1
|
|
حجم فایل
|
95.475
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
26
|
مشخصات فنی
-
RoHS:
true
-
Category:
Power Supply Chip/Linear Voltage Regulators (LDO)
-
Datasheet:
Texas Instruments TPS79901QDRVRQ1
-
Output Type:
Adjustable
-
Output Current:
200mA
-
Output Voltage:
1.2V~6.5V
-
Dropout Voltage:
180mV@(200mA)
-
Output Polarity:
Positive
-
Number of Outputs:
1
-
Maximum Input Voltage:
6.5V
-
Operating Temperature:
-40°C~+125°C
-
Quiescent Current (Ground Current):
60uA
-
Power Supply Rejection Ratio (PSRR):
70dB@(100Hz),38dB@(100kHz)
-
Package:
DFN-6(2x2)
-
Manufacturer:
Texas Instruments
-
Voltage - Input (Max):
6.5V
-
Current - Quiescent (Iq):
60µA
-
Output Configuration:
Positive
-
Base Part Number:
TPS799
-
Voltage - Output (Min/Fixed):
1.2V
-
Protection Features:
Over Current, Over Temperature, Reverse Polarity, Under Voltage Lockout (UVLO)
-
Series:
Automotive, AEC-Q100
-
Packaging:
Cut Tape (CT)
-
PSRR:
70dB ~ 38dB (100Hz ~ 100kHz)
-
Supplier Device Package:
6-WSON (2x2)
-
Package / Case:
6-WDFN Exposed Pad
-
Number of Regulators:
1
-
Part Status:
Active
-
Control Features:
Enable
-
Voltage - Output (Max):
6.5V
-
Mounting Type:
Surface Mount
-
Voltage Dropout (Max):
0.18V @ 200mA
-
Current - Output:
200mA
-
detail:
Linear Voltage Regulator IC 1 Output 200mA 6-WSON (2x2)
