TPS76933QDBVRQ1 دیتاشیت

TPS76933QDBVRQ1

مشخصات دیتاشیت

نام دیتاشیت TPS76933QDBVRQ1
حجم فایل 107.19 کیلوبایت
نوع فایل pdf
تعداد صفحات 23

دانلود دیتاشیت TPS76933QDBVRQ1

دانلود دیتاشیت

سایر مستندات

TPS769xx-Q1 Datasheet 23 pages

مشخصات فنی

  • RoHS: true
  • Category: Power Supply Chip/Linear Voltage Regulators (LDO)
  • Datasheet: Texas Instruments TPS76933QDBVRQ1
  • Output Current: 100mA
  • Output Voltage: 3.3V
  • Dropout Voltage: 0.2V@(100mA)
  • Output Polarity: positive
  • Number of Outputs: 1
  • Maximum Input Voltage: 10V
  • Operating Temperature: -40°C~+125°C
  • Quiescent Current (Ground Current): 28uA
  • Power Supply Rejection Ratio (PSRR): 60dB@(1kHz)
  • Package: SOT-23-5
  • Manufacturer: Texas Instruments
  • Voltage - Input (Max): 10V
  • Current - Quiescent (Iq): 28µA
  • Output Configuration: Positive
  • Base Part Number: TPS769
  • Voltage - Output (Min/Fixed): 3.3V
  • Protection Features: Over Current, Over Temperature, Reverse Polarity
  • Series: Automotive, AEC-Q100
  • Packaging: Cut Tape (CT)
  • PSRR: 60dB (1kHz)
  • Supplier Device Package: SOT-23-5
  • Package / Case: SC-74A, SOT-753
  • Number of Regulators: 1
  • Part Status: Active
  • Output Type: Fixed
  • Control Features: Enable
  • Voltage - Output (Max): -
  • Mounting Type: Surface Mount
  • Voltage Dropout (Max): 0.2V @ 100mA
  • Current - Output: 100mA
  • detail: Linear Voltage Regulator IC 1 Output 100mA SOT-23-5
