دیتاشیت CD4068BE

CD4068B Types

مشخصات دیتاشیت

نام دیتاشیت CD4068B Types
حجم فایل 1296.496 کیلوبایت
نوع فایل pdf
تعداد صفحات 17

دانلود دیتاشیت CD4068B Types

CD4068B Types Datasheet

مشخصات

  • RoHS: true
  • Series: 4000B
  • Category: Logic ICs/Gates
  • Datasheet: Texas Instruments CD4068BE
  • Sink Current: 6.8mA
  • Source Current: 6.8mA
  • Supply Voltage: 3V~18V
  • Logic Gate Type: NAND Gates;And
  • Number of Channels: 1
  • Operating Temperature: -55°C~+125°C
  • Package: PDIP-14
  • Manufacturer: Texas Instruments
  • Mounting Type: Through Hole
  • Logic Type: NAND/AND Gate
  • Voltage - Supply: 3V ~ 18V
  • Part Status: Active
  • Number of Circuits: 1
  • Packaging: Tube
  • Package / Case: 14-DIP (0.300", 7.62mm)
  • Current - Output High, Low: 6.8mA, 6.8mA
  • Output Type: Single-Ended
  • Supplier Device Package: 14-PDIP
  • Number of Inputs: 8
  • Schmitt Trigger Input: No
  • Base Part Number: CD4068
  • detail: NAND/AND Gate Configurable 1 Circuit 8 Input 14-PDIP
