CD74HCT175E دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
CD74HCT175E
|
|
حجم فایل
|
97.812
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
16
|
مشخصات فنی
-
RoHS:
true
-
Type:
D-Type
-
Series:
74HCT
-
Category:
Logic ICs/Flip Flops
-
Function:
Reset
-
Datasheet:
Texas Instruments CD74HCT175E
-
Output Type:
互补型
-
Sink Current:
4mA
-
Trigger Type:
上升沿
-
Source Current:
4mA
-
Supply Voltage:
4.5V~5.5V
-
Clock Frequency:
25MHz
-
Input Capacitance:
10pF
-
Number of Channels:
4
-
Operating Temperature:
-55°C~+125°C
-
Quiescent Current (Iq):
8uA
-
Maximum Propagation Delay:
33ns@4.5V,50pF
-
Package:
PDIP-16
-
Manufacturer:
Texas Instruments
-
Number of Elements:
1
-
Voltage - Supply:
4.5V ~ 5.5V
-
Package / Case:
16-DIP (0.300", 7.62mm)
-
Packaging:
Tube
-
Supplier Device Package:
16-PDIP
-
Number of Bits per Element:
4
-
Current - Output High, Low:
4mA, 4mA
-
Part Status:
Active
-
Base Part Number:
74HCT175
-
Mounting Type:
Through Hole
-
Current - Quiescent (Iq):
8µA
-
Max Propagation Delay @ V, Max CL:
33ns @ 4.5V, 50pF
-
detail:
Flip Flop 1 Element D-Type 4 Bit Positive Edge 16-DIP (0.300", 7.62mm)
