- دیتاشیت ACST410-8B
ACST410-8B دیتاشیت
مشخصات دیتاشیت
| نام دیتاشیت | ACST410-8B |
|---|---|
| حجم فایل | 71.505 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 14 |
دانلود دیتاشیت ACST410-8B |
دانلود دیتاشیت |
|---|
سایر مستندات
ACST4 16 pages
ACST410-8B 13 pages
مشخصات فنی
- RoHS: true
- Category: Triode/MOS Tube/Transistor/TRIACs
- SCR Type: 门极灵敏型-High Speed
- Datasheet: STMicroelectronics ACST410-8B
- Holding Current (Ih): 20mA
- Operating Temperature: -40°C~+125°C@(Tj)
- Gate Trigger Current(Igt): 10mA
- Gate Trigger Voltage (Vgt): 1V
- RMS On-State Current(It (rms)): 4A
- Peak Repetitive Off?State Voltage (Vdrm): 800V
- Package: TO-252-2(DPAK)
- Manufacturer: STMicroelectronics
- Series: ACS™/A.S.D®
- Packaging: Tube
- Part Status: Obsolete
- Triac Type: Logic - Sensitive Gate
- Voltage - Off State: 800V
- Current - On State (It (RMS)) (Max): 4A
- Voltage - Gate Trigger (Vgt) (Max): 1V
- Current - Non Rep. Surge 50, 60Hz (Itsm): 30A, 32A
- Current - Gate Trigger (Igt) (Max): 10mA
- Current - Hold (Ih) (Max): 20mA
- Configuration: Single
- Mounting Type: Surface Mount
- Package / Case: TO-252-3, DPak (2 Leads + Tab), SC-63
- Supplier Device Package: DPAK
- Base Part Number: ACST410
- detail: TRIAC Logic - Sensitive Gate 800V 4A Surface Mount DPAK
