دیتاشیت CD54,74HC(T)4066
مشخصات دیتاشیت
| نام دیتاشیت |
CD54,74HC(T)4066
|
| حجم فایل |
1082.26
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
21
|
مشخصات فنی
-
RoHS:
true
-
Category:
Communication Interface Chip/UART/485/232/Analog Switches / Multiplexers
-
Datasheet:
Texas Instruments CD74HC4066E
-
Supply Voltage:
2V~10V
-
Switch Circuit:
SPST(SPST)-Normal Open
-
Number of Channels:
4
-
On-State Resistance (Max):
70Ω
-
Package:
PDIP-14
-
Manufacturer:
Texas Instruments
-
Current - Leakage (IS(off)) (Max):
100nA
-
Voltage - Supply, Single (V+):
2V ~ 10V
-
Voltage - Supply, Dual (V±):
-
-
Number of Circuits:
4
-
Channel-to-Channel Matching (ΔRon):
500mOhm
-
Package / Case:
14-DIP (0.300", 7.62mm)
-
Part Status:
Active
-
Supplier Device Package:
14-PDIP
-
Switch Time (Ton, Toff) (Max):
-
-
Packaging:
Tube
-
-3db Bandwidth:
200MHz
-
Operating Temperature:
-55°C ~ 125°C (TA)
-
Mounting Type:
Through Hole
-
Crosstalk:
-72dB @ 1MHz
-
Base Part Number:
74HC4066
-
Series:
-
-
Channel Capacitance (CS(off), CD(off)):
5pF
-
Multiplexer/Demultiplexer Circuit:
1:1
-
Charge Injection:
-
-
detail:
4 Circuit IC Switch 1:1 70Ohm 14-PDIP
