L5981TR دیتاشیت

مشخصات دیتاشیت

مشاهده دیتاشیت L5981TR	دانلود دیتاشیت

L5981 37 pages

L5981TR 37 pages

RoHS: true
Category: Power Supply Chip/DC-DC Converters
Function: Step-down type
Topology: Step-down
Datasheet: STMicroelectronics L5981TR
Output Type: Adjustable
Input Voltage: 2.9V~18V
Output Voltage: 0.6V~18V
Number of Outputs: 1
Switching Frequency: 1MHz
Output Current (Max): 1A
Operating Temperature: -40°C~+150°C@(TJ)
Synchronous Rectification: NO
Package: VFQFPN-8(3x3)
Manufacturer: STMicroelectronics
Series: -
Packaging: Cut Tape (CT)
Part Status: Active
Output Configuration: Positive
Voltage - Input (Min): 2.9V
Voltage - Input (Max): 18V
Voltage - Output (Min/Fixed): 0.6V
Voltage - Output (Max): 18V
Current - Output: 1A
Frequency - Switching: 250kHz ~ 1MHz
Synchronous Rectifier: No
Mounting Type: Surface Mount
Package / Case: 8-VFDFN Exposed Pad
Supplier Device Package: 8-VFQFPN (3x3)
Base Part Number: L5981
detail: Buck Switching Regulator IC Positive Adjustable 0.6V 1 Output 1A 8-VFDFN Exposed Pad
