دیتاشیت CD4556BE
مشخصات دیتاشیت
| نام دیتاشیت | CD4555B, CD4556B Datasheet |
|---|---|
| حجم فایل | 1350.26 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 19 |
دانلود دیتاشیت CD4555B, CD4556B Datasheet |
CD4555B, CD4556B Datasheet Datasheet |
|---|
مشخصات
- RoHS: true
- Type: Decoder/Demultiplexers
- Category: Logic ICs/Signal Switches / Encoders & Decoders / Multiplexers
- Datasheet: Texas Instruments CD4556BE
- Sink Current: 6.8mA
- Source Current: 6.8mA
- Supply Voltage: 3V~18V
- Operating temperature: -55°C~+125°C
- Voltage Supply Source: Dual Power
- Package: PDIP-16
- Manufacturer: Texas Instruments
- Independent Circuits: 2
- Voltage - Supply: 3V ~ 18V
- Circuit: 1 x 2:4
- Mounting Type: Through Hole
- Packaging: Tube
- Package / Case: 16-DIP (0.300", 7.62mm)
- Part Status: Active
- Current - Output High, Low: 6.8mA, 6.8mA
- Series: 4000B
- Supplier Device Package: 16-PDIP
- Base Part Number: CD4555
- detail: Decoder/Demultiplexer 1 x 2:4 16-PDIP
