TPS73501QDRBRQ1 دیتاشیت

مشخصات دیتاشیت

دانلود دیتاشیت TPS73501QDRBRQ1	دانلود دیتاشیت

RoHS: true
Category: Power Supply Chip/Linear Voltage Regulators (LDO)
Datasheet: Texas Instruments TPS73501QDRBRQ1
Output Type: Adjustable
Output Current: 500mA
Output Voltage: 1.25V~6V
Dropout Voltage: 0.17V@(500mA)
Output Polarity: positive
Number of Outputs: 1
Maximum Input Voltage: 6.5V
Operating Temperature: -40°C~+125°C
Quiescent Current (Ground Current): 65uA
Package: SON-8-EP(3x3)
Manufacturer: Texas Instruments
Voltage - Input (Max): 6.5V
Current - Quiescent (Iq): 65µA
Output Configuration: Positive
Base Part Number: TPS735
Voltage - Output (Min/Fixed): 1.25V
Protection Features: Over Current, Over Temperature, Under Voltage Lockout (UVLO)
Series: Automotive, AEC-Q100
Packaging: Cut Tape (CT)
PSRR: 53dB ~ 51dB (120Hz)
Supplier Device Package: 8-SON (3x3)
Package / Case: 8-VDFN Exposed Pad
Number of Regulators: 1
Part Status: Active
Control Features: Enable
Voltage - Output (Max): 6V
Mounting Type: Surface Mount
Voltage Dropout (Max): 0.17V @ 500mA
Current - Output: 500mA
detail: Linear Voltage Regulator IC 1 Output 500mA 8-SON (3x3)
