- دیتاشیت TLC3704IPWR
TLC3704IPWR دیتاشیت
مشخصات دیتاشیت
| نام دیتاشیت | TLC3704IPWR |
|---|---|
| حجم فایل | 102.023 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 38 |
دانلود دیتاشیت TLC3704IPWR |
دانلود دیتاشیت |
|---|
سایر مستندات
TLC3704, TLC3704Q 38 pages
مشخصات فنی
- RoHS: true
- Category: Operational Amplifier/Comparator/Comparators
- Datasheet: Texas Instruments TLC3704IPWR
- Output Type: Push Pull
- Supply Voltage: 3V~16V
- Number of Elements: -
- Operating Temperature: -40°C~+85°C
- Input Bias Current (Ib): 5pA
- Input Offset Voltage (Vos): 5mV
- Input Hysteresis Voltage (Vhys): -
- Common Mode Rejection Ratio (CMRR): 74dB
- Package: TSSOP-14
- Manufacturer: Texas Instruments
- Package / Case: 14-TSSOP (0.173", 4.40mm Width)
- Propagation Delay (Max): 4.5µs
- Current - Quiescent (Max): 125µA
- Voltage - Input Offset (Max): 5mV @ 10V
- Part Status: Active
- Current - Output (Typ): 20mA
- Current - Input Bias (Max): 5pA @ 5V
- Packaging: Cut Tape (CT)
- Type: General Purpose
- CMRR, PSRR (Typ): 84dB CMRR
- Voltage - Supply, Single/Dual (±): 3V ~ 16V
- Series: LinCMOS™
- Base Part Number: TLC370
- Supplier Device Package: 14-TSSOP
- Mounting Type: Surface Mount
- Hysteresis: -
- detail: Comparator General Purpose CMOS, Push-Pull, TTL 14-TSSOP
