LM78Lxx Datasheet Datasheet

LM78Lxx Datasheet

Datasheet specifications

Datasheet's name LM78Lxx Datasheet
File size 1905.246 KB
File type pdf
Number of pages 34

Download Datasheet LM78Lxx Datasheet

Download Datasheet

Other documentations

TO-92 Packing Options 6 pages

Technical specifications

  • Manufacturer: Texas Instruments
  • Voltage - Input (Max): 35V
  • Current - Quiescent (Iq): 3mA
  • Output Configuration: Positive
  • Base Part Number: LM78L15
  • Voltage - Output (Min/Fixed): 15V
  • Protection Features: Over Temperature, Short Circuit
  • Series: -
  • Packaging: Bulk
  • PSRR: 51dB (120Hz)
  • Supplier Device Package: TO-92-3
  • Package / Case: TO-226-3, TO-92-3 (TO-226AA)
  • Number of Regulators: 1
  • Operating Temperature: 0°C ~ 125°C
  • Part Status: Active
  • Output Type: Fixed
  • Control Features: -
  • Voltage - Output (Max): -
  • Mounting Type: Through Hole
  • Voltage Dropout (Max): -
  • Current - Output: 100mA
  • detail: Linear Voltage Regulator IC 1 Output 100mA TO-92-3
