L99MC6GJTR دیتاشیت

مشخصات دیتاشیت

مشاهده دیتاشیت L99MC6GJTR	دانلود دیتاشیت

L99MC6GJ 55 pages

RoHS: true
Category: Power Supply Chip/Power Distribution Switches
Datasheet: STMicroelectronics L99MC6GJTR
Input Voltage: 6V~28V
Output Current: 600mA
Number of Outputs: 6
Resistor On-State: 700mΩ
Operating Temperature -: -40°C~+150°C
Package: PowerSSO-16
Manufacturer: STMicroelectronics
Series: -
Packaging: Cut Tape (CT)
Part Status: Active
Switch Type: General Purpose
Ratio - Input:Output: 1:6
Output Configuration: High Side or Low Side
Output Type: N-Channel
Interface: SPI
Voltage - Load: 6V ~ 28V
Voltage - Supply (Vcc/Vdd): 3V ~ 5.25V
Current - Output (Max): 600mA
Rds On (Typ): 700mOhm
Input Type: Non-Inverting
Features: PWM Input, Slew Rate Controlled
Fault Protection: Current Limiting (Fixed), Open Load Detect, Over Temperature
Operating Temperature: -40°C ~ 150°C (TJ)
Mounting Type: Surface Mount
Supplier Device Package: PowerSSO-16
Package / Case: 16-PowerLFSOP (0.154", 3.90mm Width)
Base Part Number: L99M
detail: Power Switch/Driver 1:6 N-Channel 600mA PowerSSO-16
