TPS61240IDRVRQ1 دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
TPS61240IDRVRQ1
|
|
حجم فایل
|
86.697
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
27
|
مشخصات فنی
-
RoHS:
true
-
Category:
Power Supply Chip/DC-DC Converters
-
Function:
boost converterType
-
Topology:
Boost
-
Datasheet:
Texas Instruments TPS61240IDRVRQ1
-
Output Type:
Fixed
-
Input Voltage:
2.3V~5.5V
-
Output Voltage:
5V
-
Number of Outputs:
1
-
Switching Frequency:
3.5MHz
-
Output Current (Max):
500mA
-
Operating Temperature:
-40°C~+85°C@(TA)
-
Synchronous Rectification:
Yes
-
Package:
DFN-6(2x2)
-
Manufacturer:
Texas Instruments
-
Current - Output:
500mA (Switch)
-
Voltage - Input (Max):
5.5V
-
Frequency - Switching:
3.5MHz
-
Part Status:
Active
-
Base Part Number:
TPS612
-
Voltage - Output (Min/Fixed):
5V
-
Package / Case:
6-WDFN Exposed Pad
-
Series:
Automotive, AEC-Q100
-
Packaging:
Digi-Reel®
-
Synchronous Rectifier:
Yes
-
Output Configuration:
Positive
-
Voltage - Output (Max):
-
-
Mounting Type:
Surface Mount
-
Supplier Device Package:
6-WSON (2x2)
-
Voltage - Input (Min):
2.3V
-
detail:
Boost Switching Regulator IC Positive Fixed 5V 1 Output 500mA (Switch) 6-WDFN Exposed Pad
