دیتاشیت M74HC374RM13TR

M74HC374

مشخصات دیتاشیت

نام دیتاشیت M74HC374
حجم فایل 245.097 کیلوبایت
نوع فایل pdf
تعداد صفحات 11

دانلود دیتاشیت M74HC374

M74HC374 Datasheet

مشخصات

  • RoHS: true
  • Type: D-Type
  • Series: 74HC
  • Category: Logic ICs/Flip Flops
  • Function: -
  • Datasheet: STMicroelectronics M74HC374RM13TR
  • Output Type: Tri-State;Non-Inverted
  • Package: SOIC-20-300mil
  • Manufacturer: STMicroelectronics
  • Packaging: Cut Tape (CT)
  • Part Status: Obsolete
  • Number of Elements: 1
  • Number of Bits per Element: 8
  • Clock Frequency: 90MHz
  • Max Propagation Delay @ V, Max CL: 32ns @ 6V, 150pF
  • Trigger Type: Positive Edge
  • Current - Output High, Low: 7.8mA, 7.8mA
  • Voltage - Supply: 2V ~ 6V
  • Current - Quiescent (Iq): 4µA
  • Input Capacitance: 5pF
  • Operating Temperature: -55°C ~ 125°C (TA)
  • Mounting Type: Surface Mount
  • Supplier Device Package: 20-SOP
  • Package / Case: 20-SOIC (0.295", 7.50mm Width)
  • Base Part Number: M74HC374
  • detail: Flip Flop 1 Element D-Type 8 Bit Positive Edge 20-SOIC (0.295", 7.50mm Width)
