ALED7707TR دیتاشیت

ALED7707TR

مشخصات دیتاشیت

نام دیتاشیت ALED7707TR
حجم فایل 74.04 کیلوبایت
نوع فایل pdf
تعداد صفحات 36

مشاهده دیتاشیت ALED7707TR

دانلود دیتاشیت

سایر مستندات

ALED7707 Datasheet 36 pages

مشخصات فنی

  • RoHS: true
  • Type: DC-DCVoltage Stabilizer
  • Dimming: PWM
  • Category: Nixie Tube Driver/LED Driver/LED Drivers
  • Channels: 6
  • Topology: boost converter
  • Datasheet: STMicroelectronics ALED7707TR
  • Input Voltage: 4.5V~36V
  • Output Current: 85mA
  • Output Voltage: 36V
  • Switch Frequency: 250kHz~1MHz
  • Operating temperature: -40°C~+150°C
  • Package: QFN-24-EP(5x5)
  • Manufacturer: STMicroelectronics
  • Series: Automotive, AEC-Q100
  • Packaging: Tray
  • Part Status: Active
  • Internal Switch(s): Yes
  • Number of Outputs: 6
  • Voltage - Supply (Min): 4.5V
  • Voltage - Supply (Max): 36V
  • Voltage - Output: 36V
  • Current - Output / Channel: 85mA
  • Frequency: 250kHz ~ 1MHz
  • Applications: Automotive, Backlight
  • Mounting Type: Surface Mount
  • Package / Case: 24-VQFN Exposed Pad
  • Supplier Device Package: 24-QFN (5x5)
  • Base Part Number: ALED77
  • detail: LED Driver IC 6 Output DC DC Regulator Step-Up (Boost) PWM Dimming 85mA 24-QFN (5x5)
