دیتاشیت LM385Z-1.2/NOPB
مشخصات دیتاشیت
| نام دیتاشیت | LM185,LM285,LM385-1.2 |
|---|---|
| حجم فایل | 1728.021 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 30 |
دانلود دیتاشیت LM185,LM285,LM385-1.2 |
LM185,LM285,LM385-1.2 Datasheet |
|---|
مشخصات
- RoHS: true
- Category: Power Supply Chip/Voltage References
- Datasheet: Texas Instruments LM385Z-1.2/NOPB
- Tolerance: -2.43%;+2.02%
- Output Type: Fixed
- Input Voltage: -
- Output Current: 20mA
- Output Voltage: 1.235V
- Reference Type: parallel connection
- Supply Current: -
- Dynamic Impedance: -
- Noise - 10Hz to 10kHz: 60uVrms
- Operating Temperature: 0°C~+70°C@(TA)
- Noise - 1/10Hz to 10Hz: -
- Temperature Coefficient: 150ppm/°C
- Minimum Cathode Current for Regulation: 15uA
- Package: TO-92
- Manufacturer: Texas Instruments
- Mounting Type: Through Hole
- Part Status: Active
- Base Part Number: LM385
- Voltage - Output (Min/Fixed): 1.235V
- Current - Cathode: 15µA
- Current - Output: 20mA
- Packaging: Bulk
- Supplier Device Package: TO-92-3
- Package / Case: TO-226-3, TO-92-3 (TO-226AA)
- Series: -
- Current - Supply: -
- Noise - 0.1Hz to 10Hz: -
- Voltage - Input: -
- detail: Shunt Voltage Reference IC -2.43%, +2.02% TO-92-3
