TPS6224x Datasheet 数据手册
其他文档
TPS62243DRVT 32 pages
技术规格
- RoHS: true
- Category: Power Supply Chip/DC-DC Converters
- Function: Step-down type
- Topology: Step-down
- Datasheet: Texas Instruments TPS62240DRVT
- Output Type: Adjustable
- Input Voltage: 2V~6V
- Output Voltage: 0.6V~6V
- Number of Outputs: 1
- Switching Frequency: 2.25MHz
- Output Current (Max): 300mA
- Operating Temperature: -40°C~+85°C@(TA)
- Synchronous Rectification: Yes
- Package: DFN-6(2x2)
- Manufacturer: Texas Instruments
- Current - Output: 300mA
- Voltage - Input (Max): 6V
- Frequency - Switching: 2.25MHz
- Part Status: Active
- Base Part Number: TPS622
- Voltage - Output (Min/Fixed): 0.6V
- Package / Case: 6-WDFN Exposed Pad
- Series: -
- Packaging: Cut Tape (CT)
- Synchronous Rectifier: Yes
- Output Configuration: Positive
- Voltage - Output (Max): 6V
- Mounting Type: Surface Mount
- Supplier Device Package: 6-WSON (2x2)
- Voltage - Input (Min): 2V
- detail: Buck Switching Regulator IC Positive Adjustable 0.6V 1 Output 300mA 6-WDFN Exposed Pad
