دیتاشیت STPS40170CG-TR
مشخصات دیتاشیت
| نام دیتاشیت |
STPS40170C
|
| حجم فایل |
589.24
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
15
|
مشخصات
-
Manufacturer:
STMicroelectronics
-
Series:
-
-
Packaging:
Cut Tape (CT)
-
Part Status:
Active
-
Diode Configuration:
1 Pair Common Cathode
-
Diode Type:
Schottky
-
Voltage - DC Reverse (Vr) (Max):
170V
-
Current - Average Rectified (Io) (per Diode):
20A
-
Voltage - Forward (Vf) (Max) @ If:
920mV @ 20A
-
Speed:
Fast Recovery =< 500ns, > 200mA (Io)
-
Current - Reverse Leakage @ Vr:
30µA @ 170V
-
Operating Temperature - Junction:
175°C (Max)
-
Mounting Type:
Surface Mount
-
Package / Case:
TO-263-3, D²Pak (2 Leads + Tab), TO-263AB
-
Supplier Device Package:
D2PAK
-
Base Part Number:
STPS401
-
detail:
Diode Array 1 Pair Common Cathode Schottky 170V 20A Surface Mount TO-263-3, D²Pak (2 Leads + Tab), TO-263AB
