دیتاشیت UA723CN
مشخصات دیتاشیت
| نام دیتاشیت |
UA723
|
| حجم فایل |
793.448
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
20
|
مشخصات
-
RoHS:
true
-
Category:
Power Supply Chip/Linear Voltage Regulators (LDO)
-
Datasheet:
Texas Instruments UA723CN
-
Output Type:
Adjustable
-
Output Current:
150mA
-
Output Voltage:
2V~37V
-
Dropout Voltage:
-
-
Output Polarity:
Positive
-
Number of Outputs:
1
-
Maximum Input Voltage:
40V
-
Operating Temperature:
0°C~+70°C
-
Power Supply Rejection Ratio (PSRR):
86dB@(50Hz~10kHz)
-
Package:
DIP-14
-
Manufacturer:
Texas Instruments
-
Voltage - Input (Max):
40V
-
Output Configuration:
Positive
-
Base Part Number:
UA723
-
Voltage - Output (Min/Fixed):
2V
-
Protection Features:
-
-
Series:
-
-
Packaging:
Tube
-
PSRR:
74dB ~ 86dB (50Hz ~ 10kHz)
-
Supplier Device Package:
14-PDIP
-
Package / Case:
14-DIP (0.300", 7.62mm)
-
Number of Regulators:
1
-
Part Status:
Active
-
Control Features:
Current Limit
-
Voltage - Output (Max):
37V
-
Mounting Type:
Through Hole
-
Voltage Dropout (Max):
-
-
Current - Output:
150mA
-
detail:
Linear Voltage Regulator IC 1 Output 150mA 14-PDIP
