مشاهده دیتاشیت L6986 Datasheet	دانلود دیتاشیت

L6986TR 68 pages

RoHS: true
Category: Power Supply Chip/DC-DC Converters
Function: Step-down type
Topology: Step-down
Datasheet: STMicroelectronics L6986TR
Output Type: Adjustable
Input Voltage: 4V~38V
Output Voltage: 0.85V~38V
Number of Outputs: 1
Switching Frequency: 2MHz
Output Current (Max): 2A
Operating Temperature: -40°C~+150°C@(TJ)
Synchronous Rectification: Yes
Package: TSSOP-16-EP
Manufacturer: STMicroelectronics
Series: -
Packaging: Cut Tape (CT)
Part Status: Active
Output Configuration: Positive
Voltage - Input (Min): 4V
Voltage - Input (Max): 38V
Voltage - Output (Min/Fixed): 0.85V
Voltage - Output (Max): 38V
Current - Output: 2A
Frequency - Switching: 250kHz ~ 2MHz
Synchronous Rectifier: Yes
Mounting Type: Surface Mount
Package / Case: 16-TSSOP (0.173", 4.40mm Width)
Supplier Device Package: 16-HTSSOP
Base Part Number: L6986
detail: Buck Switching Regulator IC Positive Adjustable 0.85V 1 Output 2A 16-TSSOP (0.173", 4.40mm Width)
