دیتاشیت VIPER53SPTR-E
مشخصات دیتاشیت
| نام دیتاشیت |
VIPer53-E
|
| حجم فایل |
363.586
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
36
|
مشخصات
-
Manufacturer:
STMicroelectronics
-
Series:
VIPER™
-
Packaging:
Cut Tape (CT)
-
Part Status:
Active
-
Output Isolation:
Isolated
-
Internal Switch(s):
Yes
-
Voltage - Breakdown:
620V
-
Topology:
Flyback
-
Voltage - Start Up:
11.5V
-
Voltage - Supply (Vcc/Vdd):
8.4V ~ 19V
-
Duty Cycle:
-
-
Frequency - Switching:
Up to 300kHz
-
Power (Watts):
65W
-
Fault Protection:
Current Limiting, Over Load, Over Temperature, Short Circuit
-
Control Features:
EN, Frequency Control, Soft Start
-
Operating Temperature:
-40°C ~ 150°C (TC)
-
Package / Case:
PowerSO-10 Exposed Bottom Pad
-
Supplier Device Package:
10-PowerSO
-
Mounting Type:
Surface Mount
-
Base Part Number:
VIPER53
-
detail:
Converter Offline Flyback Topology Up to 300kHz 10-PowerSO
