دیتاشیت VNQ7E100AJTR
مشخصات دیتاشیت
| نام دیتاشیت | VNQ7E100AJ Datasheet |
|---|---|
| حجم فایل | 1067.702 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 45 |
دانلود دیتاشیت VNQ7E100AJ Datasheet |
VNQ7E100AJ Datasheet Datasheet |
|---|
مشخصات
- Manufacturer: STMicroelectronics
- Series: Automotive, AEC-Q100, VIPOWER™
- Packaging: Cut Tape (CT)
- Part Status: Active
- Switch Type: General Purpose
- Number of Outputs: 4
- Ratio - Input:Output: 1:1
- Output Configuration: High Side
- Output Type: N-Channel
- Interface: -
- Voltage - Load: 4V ~ 28V
- Voltage - Supply (Vcc/Vdd): -
- Current - Output (Max): 7.5A
- Rds On (Typ): 100mOhm
- Input Type: Non-Inverting
- Features: Auto Restart, Status Flag
- Fault Protection: Current Limiting (Fixed), Open Load Detect, Over Temperature, Over Voltage, Short Circuit, UVLO
- Operating Temperature: -40°C ~ 150°C (TJ)
- Mounting Type: Surface Mount
- Supplier Device Package: PowerSSO-16
- Package / Case: 16-PowerLFSOP (0.154", 3.90mm Width)
- detail: Power Switch/Driver 1:1 N-Channel 7.5A PowerSSO-16
