دیتاشیت REG1117A/2K5
مشخصات دیتاشیت
| نام دیتاشیت | REG1117(A) Datasheet |
|---|---|
| حجم فایل | 891.155 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 21 |
دانلود دیتاشیت REG1117(A) Datasheet |
REG1117(A) Datasheet Datasheet |
|---|
مشخصات
- RoHS: true
- Category: Power Supply Chip/Linear Voltage Regulators (LDO)
- Datasheet: Texas Instruments REG1117A/2K5
- Output Type: Adjustable
- Output Current: 1A
- Output Voltage: 1.25V~13.5V
- Dropout Voltage: 1.55V@(1A)
- Output Polarity: positive
- Number of Outputs: 1
- Maximum Input Voltage: 15V
- Operating Temperature: -40°C~+125°C
- Quiescent Current (Ground Current): 10mA
- Power Supply Rejection Ratio (PSRR): 62dB@(120Hz)
- Package: SOT-223-4
- Manufacturer: Texas Instruments
- Voltage - Input (Max): 15V
- Current - Quiescent (Iq): 10mA
- Output Configuration: Positive
- Base Part Number: REG111
- Voltage - Output (Min/Fixed): 1.25V
- Protection Features: Over Current, Over Temperature
- Series: -
- Packaging: Cut Tape (CT)
- PSRR: 62dB (120Hz)
- Supplier Device Package: SOT-223-4
- Package / Case: TO-261-4, TO-261AA
- Number of Regulators: 1
- Part Status: Active
- Control Features: -
- Voltage - Output (Max): 13.5V
- Mounting Type: Surface Mount
- Voltage Dropout (Max): 1.55V @ 1A
- Current - Output: 1A
- detail: Linear Voltage Regulator IC 1 Output 1A SOT-223-4
