SM30T21AY دیتاشیت

SM30T21AY

مشخصات دیتاشیت

نام دیتاشیت SM30T21AY
حجم فایل 242.46 کیلوبایت
نوع فایل pdf
تعداد صفحات 13

دانلود دیتاشیت SM30T21AY

دانلود دیتاشیت

سایر مستندات

SM30TY Series 16 pages

ST SM30T33AY 16 pages

مشخصات فنی

  • RoHS: true
  • Category: TVS/Fuse/Board Level Protection/TVS
  • Datasheet: STMicroelectronics SM30T21AY
  • Breakdown Voltage: 20V
  • Unidirectional Channels: 1
  • Maximum Clamping Voltage: 29.2V
  • Reverse Leakage Current (Ir): 0.2uA
  • Reverse Stand-Off Voltage (Vrwm): 18V
  • Peak Pulse Current (Ipp)@10/1000us: 102.7A
  • Peak Pulse Power Dissipation (Ppp)@10/1000us: 3kW
  • Package: SMC(DO-214AB)
  • Manufacturer: STMicroelectronics
  • Series: Automotive, AEC-Q101, SM30TY, TRANSIL™
  • Packaging: Cut Tape (CT)
  • Part Status: Active
  • Type: Zener
  • Voltage - Reverse Standoff (Typ): 18V
  • Voltage - Breakdown (Min): 20V
  • Voltage - Clamping (Max) @ Ipp: 29.2V
  • Current - Peak Pulse (10/1000µs): 102.7A
  • Power - Peak Pulse: 3000W (3kW)
  • Power Line Protection: No
  • Applications: Automotive
  • Capacitance @ Frequency: -
  • Operating Temperature: -55°C ~ 175°C (TJ)
  • Mounting Type: Surface Mount
  • Package / Case: DO-214AB, SMC
  • Supplier Device Package: SMC (DO-214AB)
  • Base Part Number: SM30T
  • detail: 29.2V Clamp 102.7A Ipp Tvs Diode Surface Mount SMC (DO-214AB)
